Спецификации

• Application

  Saturated steam,
  steam condensate

• Body material

  Brass

• Max. operating pressure

  13 bar

• Max. operating temperature

  200 ºC

• Flow rate capacity

  Up to 360 kg/h

• Differential pressure

  Delta P: 13 bar

• Type thermostat

  Thermostats for different sub coolings 10 ºC (standard type S thermostat),
  Thermostats for 5 ºC (type H) and 30 ºC (type L) also available

• Connections

  Female threaded ISO 7 Rp
