Specyfikacje

• Application

  Saturated and superheated steam,
  steam condensate

• Body material

  Carbon steel

• Max. operating pressure

  17 bar

• Min. operating pressure

  0,5 bar

• Max. operating temperature

  250 ºC

• Differential pressure

  Delta P: 17 bar

• Flow rate capacity

  Hot condensate discharge 10 ºC below saturation temperature: Up to 600 kg/h,
  Cold condensate discharge at 20 ºC: Up to 1850 kg/h

• Connections

  Female threaded ISO 7 Rp (NPT on request),
  Flanged EN 1092-1 PN 40,
  Flanged ASME B16.5 Class 150 or 300 on request,
  Socket weld (SW) ASME B16.11 on request,
  Butt weld (BW) ASME B16.25 on request
