Specifications

• Application

  Cold, hot and superheated water,
  Oil,
  non-toxic fluid with a min. specific gravity of 0,75 kg/dm³

• Body material

  Stainless steel A351 CF8M

• Max. operating pressure

  30 bar

• Max. operating temperature

  Up to 300 ºC

• Flow rate capacity

  Up to 746 NL/min,
  Values shown refer to capacities of air discharge at 15 ºC, under average atmospheric pressure (1013 mbar)

• Differential pressure

  Delta P max.: 30 bar,
  Delta P min.: 0,5 bar

• Valve sealing

  metal to metal

• Type

  Sealed model

• Option

  Version with Inlet flanged, outlet threaded

• Connections

  Female threaded ISO 7 Rp (NPT on request)
