Home → Catalogue → Pressure control → Pressure regulators → Pressure sustaining valve ADCA PSW46BS EN direct acting, piston, water/gases, with diaphragm actuator
Valsteam ADCA
Pressure sustaining valve ADCA PSW46BS EN direct acting, piston, water/gases, with diaphragm actuator

Specifications

  • Application

    Water and liquids,
    Compressed air and other gases

  • Body material

    Carbon steel A216 WCB

  • Max. upstream pressure

    Up to 13 bar (Body design PN16),
    Up to 18 bar (Body design PN40)

  • Min. upstream pressure

    0,2 bar

  • Max. operating temperature

    EPDM sealing for water and gases up to 130 ºC

  • Regulating range of upstream pressure

    0,2 to 13 bar (Body design PN16),
    0,2 to 18 bar (Body design PN40)

  • Flow rate coefficients

    26,5 to 129,5 Kvs (m³/h)

  • Connections

    Flanged EN 1092-1 PN 16 or PN 40

Pressure sustaining valve ADCA PSW46BS EN direct acting, piston, water/gases, with diaphragm actuator

Product code: PSW46BS

Available on request

Price according to configuration

Choose your configuration
See all configuration
Ref.#.
ex. VAT
(INDICATIVE PRICE)

Quantity

-
+

No ready-made solution

The selected configuration has been added to the cart

Go to quotation request

The ADCA PSW46B series pressure sustaining valves are single seated, diaphragm or piston sensing proportional controllers that operate without auxiliary energy. Designed for use with water, compressed air and other liquids and gases compatible with the construction.
