Specifications

• Application

  For boiler water, Steam or condensate sampling

• Material

  Stainless steel body and coil

• Available models

  SC332/SS – double-coil length 665/89 mm.,
  SC432/SS – double-coil length 631/141 mm.,
  SC532/SS – double-coil length 731/141 mm.

• Max. operating pressure

  20 bar (body) / 130 bar (coil)

• Max. operating temperature

  100 ºC (body) / 500 ºC (coil)

• Flow rate capacity

  30 to 60 kg/h of sample liquid at ≈30 ºC with 1 m³/h of inlet cooling water at 15 ºC.

• Cooling water inlet and outlet connections

  SC332 – 1/2” on body (female threaded ISO 7 Rp and NPT on request),
  SC432 / SC532 – 3/4” on body (female threaded ISO 7 Rp and NPT on request)

• Sample tube inlet and outlet connections

  Compression fittings 3/8” x 10 mm on sample inlet/outlet
