Specifications

• Use

  Used to produce hot water (approx. up to 5900 L/h) using steam directly in the production area.

• Application

  Saturated steam and cold water

• Materials

  Stainless steel body and internal components

• Max. operating steam pressure

  10 bar

• Min. operating steam pressure

  2,5 bar

• Remarks:

  Steam pressure must not exceed more than 3 times the water pressure.,
  The water pressure cannot be higher than the steam pressure.

• Max capacity – hot water flow

  Approx. up to 5900 L/h,
  Min.: from 600 L/h

• Рot water outlet temperatures

  From 45 ºC to 95 ºC.

• Temperature limited

  Up to 164 ºC for saturated steam cleaning operations (short peaks) – limited to a working pressure of 6 bar.,
  Sterilisation up to 130 ºC for a max. time of 30 minutes.

• Connections

  Female threaded ISO 7 Rp.
