Public offer Prima Steam – Relible supplier equipment for your flow control!
Home → Catalogue → Pressure control

Pressure regulators

Refine

Show:
10 per page
  • 10 products per page
  • 25 products per page
  • 50 products per page
Sort:
Relevance
  • Relevance
  • Created at
  • Product code
  • Name
  • Available

  • Valsteam ADCA

    PRV25-2S

    Product code: PRV25-2S

    Pressure reducing valve ADCA PRV25/2S direct acting bellows operated, steam

    • Application

      Steam,
      Saturated steam

    • Body material

      Carbon steel

    • Max. upstream pressure

      Up to 17 bar

    • Max. operating temperature

      Graphite filled PTFE valve sealing: 200 ºC,
      Metal to metal sealing: 210 ºC

    • Regulating range

      0,14 to 8,6 bar

    • Flow rate coefficients

      1,7 to 3,1 Kvs

    • Flow rate capacity

      Saturated steam – Up to 543 (kg/h)

    • Connections

      Female threaded ISO 7 Rp (NPT on request),
      Flanged EN 1092-1 PN 25,
      Flanged ASME B16.5 Class 150 on request

    Dimension:
    1/2” – 1”; DN15 – DN25
    Price according to configuration
    Available to Order
    More about the product

  • Valsteam ADCA

    PRW25-2S

    Product code: PRW25-2S

    Pressure reducing valve ADCA PRW25/2S direct acting bellows operated, water/gases

    • Application

      Water,
      Compressed air and other gases

    • Body material

      Carbon steel

    • Max. upstream pressure

      Up to 14 bar

    • Max. operating temperature

      NBR sealing for water and gases up to 80 ºC

    • Regulating range

      0,35 to 8,6 bar

    • Flow rate coefficients

      1,7 to 3,1 Kvs

    • Flow rate capacity

      Compressed air – Up to 604 (Nm³/h),
      Water – Up to 10,15 (m³/h)

    • Connections

      Female threaded ISO 7 Rp (NPT on request),
      Flanged EN 1092-1 PN 25,
      Flanged ASME B16.5 Class 150 on request

    Dimension:
    1/2” – 1”; DN15 – DN25
    Price according to configuration
    Available on request
    More about the product

  • Valsteam ADCA

    PRV25-2i

    Product code: PRV25-2i

    Pressure reducing valve ADCA PRV25/2i direct acting bellows operated, steam

    • Application

      Steam,
      Saturated steam

    • Body material

      Stainless steel A351 CF8M

    • Max. upstream pressure

      Up to 17 bar

    • Max. operating temperature

      Graphite filled PTFE valve sealing: 200 ºC,
      Metal to metal sealing: 210 ºC

    • Regulating range

      0,14 to 8,6 bar

    • Flow rate coefficients

      1,7 to 3,1 Kvs

    • Flow rate capacity

      Saturated steam – Up to 543 (kg/h)

    • Connections

      Female threaded ISO 7 Rp (NPT on request),
      Flanged EN 1092-1 PN 25,
      Flanged ASME B16.5 Class 150 on request

    Dimension:
    1/2” – 1”; DN15 – DN25
    Price according to configuration
    Available on request
    More about the product

  • Valsteam ADCA

    PRW25-2i

    Product code: PRW25-2i

    Pressure reducing valve ADCA PRW25/2i direct acting bellows operated, water/gases

    • Application

      Water and liquids,
      Compressed air and other gases

    • Body material

      Stainless steel A351 CF8M

    • Max. upstream pressure

      Up to 14 bar

    • Max. operating temperature

      NBR sealing for water and gases up to 80 ºC

    • Regulating range

      0,35 to 8,6 bar

    • Flow rate coefficients

      1,7 to 3,1 Kvs

    • Flow rate capacity

      Compressed air – Up to 604 (Nm³/h),
      Water – Up to 10,15 (m³/h)

    • Connections

      Female threaded ISO 7 Rp (NPT on request),
      Flanged EN 1092-1 PN 25,
      Flanged ASME B16.5 Class 150 on request

    Dimension:
    1/2” – 1”; DN15 – DN25
    Price according to configuration
    Available on request
    More about the product

  • Valsteam ADCA

    RP45S-thread

    Product code: RP45S-thread

    Pressure reducing valve ADCA RP45S (Threaded) direct acting, steam, with diaphragm actuator

    • Application

      Steam,
      Saturated steam

    • Body material

      Carbon steel A216 WCB

    • Max. upstream pressure

      Up to 25 bar

    • Max. operating temperature

      PTFE/Graphite sealing for steam up to 200 ºC,
      metal to metal sealing for steam: 250 ºC

    • Regulating range

      0,15 to 18 bar

    • Flow rate coefficients

      4,8 to 26,5 Kvs

    • Flow rate capacity

      Saturated steam – Up to 9200 (kg/h)

    • Connections

      Female threaded ISO 7 Rp PN 40 (NPT on request)

    Dimension:
    1/2” – 2”
    Price according to configuration
    Available on request
    More about the product

  • Valsteam ADCA

    RP45SN-thread

    Product code: RP45SN-thread

    Pressure reducing valve ADCA RP45SN (Threaded) direct acting, water/gases, with diaphragm actuator

    • Application

      Water and liquids,
      Compressed air and other gases

    • Body material

      Carbon steel A216 WCB

    • Max. upstream pressure

      Up to 25 bar

    • Max. operating temperature

      NBR sealing for water and gases up to 80 ºC

    • Regulating range

      0,15 to 18 bar

    • Flow rate coefficients

      4,8 to 26,5 Kvs (m³/h)

    • Connections

      Female threaded ISO 7 Rp PN 40 (NPT on request)

    Dimension:
    1/2” – 2”
    Price according to configuration
    Available on request
    More about the product

  • Valsteam ADCA

    RP45i-thread

    Product code: RP45i-thread

    Pressure reducing valve ADCA RP45i (Threaded) direct acting, steam, with diaphragm actuator

    • Application

      Steam,
      Saturated steam

    • Body material

      Stainless steel A351 CF8M

    • Max. upstream pressure

      Up to 25 bar

    • Max. operating temperature

      PTFE/Graphite sealing for steam up to 200 ºC,
      metal to metal sealing for steam: 250 ºC

    • Regulating range

      0,15 to 18 bar

    • Flow rate coefficients

      4,8 to 26,5 Kvs

    • Flow rate capacity

      Saturated steam – Up to 9200 (kg/h)

    • Connections

      Female threaded ISO 7 Rp PN 40 (NPT on request)

    Dimension:
    1/2” – 2”
    Price according to configuration
    Available on request
    More about the product

  • Valsteam ADCA

    RP45iN-thread

    Product code: RP45iN-thread

    Pressure reducing valve ADCA RP45iN (Threaded) direct acting, water/gases, with diaphragm actuator

    • Application

      Water and liquids,
      Compressed air and other gases

    • Body material

      Stainless steel A351 CF8M

    • Max. upstream pressure

      Up to 25 bar

    • Max. operating temperature

      NBR sealing for water and gases up to 80 ºC

    • Regulating range

      0,15 to 18 bar

    • Flow rate coefficients

      4,8 to 26,5 Kvs (m³/h)

    • Connections

      Female threaded ISO 7 Rp PN 40 (NPT on request)

    Dimension:
    1/2” – 2”
    Price according to configuration
    Available on request
    More about the product

  • Valsteam ADCA

    RP45G-STEAM

    Product code: RP45G-STEAM

    Pressure reducing valve ADCA RP45G direct acting, steam, with diaphragm actuator

    • Application

      Steam,
      Saturated steam

    • Body material

      Ductile iron GJS-400-15

    • Max. upstream pressure

      Up to 13 bar

    • Max. operating temperature

      PTFE/Graphite sealing for steam up to 200 ºC,
      metal to metal sealing for steam: 200 ºC

    • Regulating range

      0,15 to 13 bar

    • Flow rate coefficients

      4,8 to 204 Kvs

    • Flow rate capacity

      Saturated steam – Up to 50000 (kg/h)

    • Connections

      Flanged EN 1092-2 PN 16

    Dimension:
    DN15 – DN150
    Price according to configuration
    Available to Order
    More about the product

  • Valsteam ADCA

    RP45GN-WATER

    Product code: RP45GN-WATER

    Pressure reducing valve ADCA RP45GN direct acting, water/gases, with diaphragm actuator

    • Application

      Water and liquids,
      Compressed air and other gases

    • Body material

      Ductile iron GJS-400-15

    • Max. upstream pressure

      Up to 13 bar

    • Max. operating temperature

      NBR sealing for water and gases up to 80 ºC

    • Regulating range

      0,15 to 13 bar

    • Flow rate coefficients

      4,8 to 204 Kvs (m³/h)

    • Connections

      Flanged EN 1092-2 PN 16

    Dimension:
    DN15 – DN150
    Price according to configuration
    Available on request
    More about the product
