Specifications

• Application

  Saturated steam,
  Hot and superheated water,
  Air, gases and others

• Body material

  Stainless Steel A351 CF8M & Stainless Steel U1 Trim

• Max. operating pressure

  Up to 13,4 bar (Body design PN16),
  Up to 33,7 bar (Body design PN40)

• Flow rate coefficients

  Kvs 5,1 to 40 (m³/h)

• Plug type

  parabolic quick-opening (On/Off) soft plug

• Flow direction

  Flow under the plug

• Stem sealing

  PTFE/GR V-Rings – up to 200ºC

• Valve sealing

  Soft sealed with PTFE/GR (class VI)

• Actuator

  Pneumatic air on-off piston actuator ADCATrol PPI series

• Actuator direction of action

  Air to open (standard) / Air to close

• Max. air supply pressure

  8 bar

• Connections

  Flanged EN 1092-1 PN 16 or PN 40
