Specifications

• Application

  Steam,
  Saturated steam,
  Water,
  Compressed air and other gases

• Material

  Carbon steel,
  Full stainless steel construction, on request

• Max. upstream pressure

  Up to 14 bar

• Max. operating temperature

  for saturated steam up to 210 ºC,
  for water and gases up to 80 ºC

• Regulating range

  0,14 to 8,6 bar

• Flow rate capacity

  Saturated steam – Up to 543 (kg/h),
  Water – Up to 10,15 (m³/h),
  Compressed air – Up to 604 (Nm³/h),

• Sizes

  humidity separator – 1/2” to 2”,
  pressure regulator – 1/2” to 1”

• Connections

  Female threaded ISO 7 Rp,
  Female threaded NPT ASME B1.20.1 on request
