Specifications

• Application

  Steam,
  Saturated steam,
  Compressed air and other gases

• Material

  Carbon steel,
  Full stainless steel construction, on request

• Max. upstream pressure

  Up to 28 bar

• Max. operating temperature

  for saturated steam up to 250 ºC,
  for compressed air and gases up to 180 ºC

• Regulating range

  0,07 to 17 bar

• Flow rate capacity

  Saturated steam – up to 33164 (kg/h),
  Compressed air – up to 37962 (Nm³/h)

• Sizes

  humidity separator – DN15 to DN250,
  pressure regulator – DN15 to DN100

• Connections

  Flanged EN 1092-1 PN 16 or PN 40
